Introducing our 12VDC Solenoid Door Lock – the perfect electronic lock solution for various applications! This solenoid, essentially an electromagnet, boasts a robust design with a slanted-cut slug and a sturdy mounting bracket.
Key Features:
Strong Performance: Thanks to its slanted-cut slug and reliable mounting bracket, this solenoid delivers a powerful and secure locking mechanism.
Versatile Orientation: Easily customize the solenoid’s position by rotating it 90, 180, or 270 degrees to match the door configuration of your choice.
Simple Operation: By default, the lock is active, preventing the door from opening without consuming any power. Apply 9-12VDC to activate the solenoid, allowing the door to be effortlessly opened.
Easy Installation: Utilize the two Phillips-head screws for quick installation, and follow our setup video for a step-by-step guide.
Recommended Accessories for Arduino, NodeMCU, or Raspberry Pi Integration:
For seamless integration with Arduino, NodeMCU, or Raspberry Pi, consider our recommended relay modules or breakouts. We suggest using a 5V Arduino UNO, Maker UNO, or CT-UNO in combination with our Optoisolated Single Channel H/L Relay.
Installation Instructions:
Connect the red wire to the positive terminal and the green wire to the negative terminal.
Turning on the current will unlock the mechanism, while turning it off will lock it securely.
Specifications:
- Voltage: 12VDC
- Current: 0.6A
- Latch Telescopic Length: 10mm
- Energized Forms: Intermittent
- Unlocking Time: 1 second
- Continuously Energized: <10 seconds
- Temperature Range: -40°C to +50°C
Applications:
Perfect for cabinet locks, locker locks, file cabinet locks, luggage locks, electric locks, door locks, solenoid locks, drawer locks, newspaper boxes lock, sauna lock, locker electromagnetic locks, electric locks, newspaper boxes, and sauna electronics lock.
Enhance security and convenience with our reliable 12VDC Solenoid Door Lock. Watch our setup video for a hassle-free installation guide, and explore endless possibilities for your electronic locking needs!
