1.5Amp 7V-25V DC Motor Driver (4 Channels)

FD04A – 1.5Amp 7V-25V DC Motor Driver (4 Channels)

This 1.5A 7V-25V DC Motor Driver is a versatile and compact solution for controlling up to 4 DC motors or 2 stepper motors. It operates with an input voltage range of 7V to 25V and handles up to 1.5A of current per channel, making it ideal for small to medium-sized robotics and automation projects. The onboard test buttons and motor output LEDs provide a quick and convenient way to test the motor driver without needing to connect a host controller.

The motor driver supports PWM and DIR inputs, and its inputs are compatible with 3.3V and 5V logic levels, ensuring compatibility with a wide range of host controllers such as Arduino, Raspberry Pi, and PLCs. Additionally, the motor driver features built-in thermal shutdown and overcurrent protection for reliable performance in various applications.

FD04A – 1.5Amp 7V-25V DC Motor Driver Features

• Supports up to 4 DC motors or 2 stepper motors
• 7V to 25V operating voltage range
• 1.5A maximum current per channel
• Onboard test buttons and motor output LEDs for easy testing
• Supports PWM and DIR inputs for motor control
• Compatible with 3.3V and 5V logic (works with Arduino, Raspberry Pi, PLC, etc.)
• Reverse polarity protection
• Board size: 10.67cm x 5.21cm
